Danfoss VLT AutomationDrive FC 361 Programming Guide

8-36 Max Response Delay
Range: Function:
Size
related*
[ 11 - 10001
ms]
Specify the maximum allowed delay
time between transmitting a
request and receiving a response. If
a response from the frequency
converter is exceeding the time
setting, then it is discarded.
8-37 Max Inter-Char Delay
Range: Function:
Size
related*
[ 0.00 - 35.00
ms]
Specify the maximum allowed time
interval between receipt of 2 bytes.
This parameter activates timeout if
transmission is interrupted.
This parameter is active only when
parameter 8-30 Protocol is set to [1]
FC MC protocol.
4.9.4 8-4* FC MC Protocol Set
8-40 Telegram Selection
Option: Function:
[1] * Standard
telegram 1
Enables use of freely congurable
telegrams or standard telegrams for
the FC port.
[100] None
[101] PPO 1
[102] PPO 2
[103] PPO 3
[104] PPO 4
[105] PPO 5
[106] PPO 6
[107] PPO 7
[108] PPO 8
[200] Custom
telegram 1
Enables use of freely congurable
telegrams or standard telegrams for
the FC port.
[202] Custom
telegram 3
8-41 Parameters for Signals
Option: Function:
[0] * None This parameter contains a list of
signals available for selection in
parameter 8-42 PCD Write Congu-
ration and parameter 8-43 PCD Read
Conguration.
[302] Minimum
Reference
[303] Maximum
Reference
[312] Catch up/slow
Down Value
8-41 Parameters for Signals
Option: Function:
[341] Ramp 1 Ramp
Up Time
[342] Ramp 1 Ramp
Down Time
[351] Ramp 2 Ramp
Up Time
[352] Ramp 2 Ramp
Down Time
[380] Jog Ramp
Time
[381] Quick Stop
Ramp Time
[411] Motor Speed
Low Limit
[RPM]
[412] Motor Speed
Low Limit [Hz]
[413] Motor Speed
High Limit
[RPM]
[414] Motor Speed
High Limit
[Hz]
[416] Torque Limit
Motor Mode
[417] Torque Limit
Generator
Mode
[553] Term. 29 High
Ref./Feedb.
Value
[558] Term. 33 High
Ref./Feedb.
Value
[590] Digital & Relay
Bus Control
[593] Pulse Out #27
Bus Control
[595] Pulse Out #29
Bus Control
[597] Pulse Out
#X30/6 Bus
Control
[615] Terminal 53
High Ref./
Feedb. Value
[625] Terminal 54
High Ref./
Feedb. Value
[653] Term 42
Output Bus
Ctrl
Parameter Descriptions Programming Guide
MG06J202 Danfoss A/S © 03/2019 All rights reserved. 97
