23-61 Continuous Bin Data
Range: Function:
0
*
[0 -
4294967295
]
Array with 10 elements ([0]-[9] below
parameter number in display). Press [OK] and
step between elements with [
] and [
].
10 counters with the frequency of
occurrence for the operating variable
monitored, sorted according to the following
intervals:
Counter [0]: 0% - <10%
Counter [1]: 10% - <20%
Counter [2]. 20% - <30%
Counter [3]: 30% - <40%
Counter [4]: 40% - <50%
Counter [5]: 50% - <60%
Counter [6]. 60% - <70%
Counter [7]: 70% - <80%
Counter [8]. 80% - <90%
Counter [9]: 90% - <100% or Max
The above minimum limits for the intervals
are the default limits. These can be changed
in 23-65 Minimum Bin Value.
Starts to count when the frequency
converter is powered up for the first time. All
counters can be reset to 0 in 23-66 Reset
Continuous Bin Data.
23-62 Timed Bin Data
Range: Function:
0 * [0 -
4294967295 ]
Array with 10 elements ([0]-[9] below
parameter number in display). Press [OK]
and step between elements with [
] and
[
].
10 counters with the frequency of
occurrence for the operating data
monitored sorted according to the intervals
as for 23-61 Continuous Bin Data.
Starts to count at the date/time
programmed in 23-63 Timed Period Start,
and stops at the time/date programmed in
23-64 Timed Period Stop. All counters can be
reset to 0 in 23-67 Reset Timed Bin Data.
23-63 Timed Period Start
Range: Function:
Size related* [ 0 - 0 ] Set the date and time at which the
Trending
starts the update of the Timed
Bin counters.
23-63 Timed Period Start
Range: Function:
Date format will depend on setting in
0-71
Date Format, and time format on
setting in 0-72 Time Format.
NOTE
The
frequency converter has no back up of the clock
function and the set date/time will reset to default
(2000-01-01 00:00) after a power down unless a Real Time
Clock module with back up is installed. Consequently, the
logging will be stopped until date/time is readjusted in
0-70 Set Date and Time. In 0-79 Clock Fault it is possible to
program for a Warning in case clock not has been set
properly, e.g. after a power down.
NOTE
When
mounting an Analog I/O MCB 109 option card, a
battery back up of the date and time is included.
23-64 Timed Period Stop
Range: Function:
Size related* [ 0 - 0 ] Set the date and time at which the Trend
Analyses
must stop update of the Timed
Bin counters.
Date format will depend on setting in
0-71 Date Format, and time format on
setting in 0-72 Time Format.
NOTE
When
mounting an Analog I/O MCB 109 option card, a
battery back up of the date and time is included.
23-65 Minimum Bin Value
Range: Function:
Size
related*
[ 0 -
100
%]
Array with 10 elements ([0]-[9] below
parameter number in display). Press [OK] and
step between elements with [
] and [
].
Set the minimum limit for each interval in
23-61 Continuous Bin Data and 23-62 Timed
Bin Data. Example: if selecting [1] counter
and changing setting from 10% to 12%, [0]
counter will be based on the interval 0 -
<12% and [1] counter on interval 12% -
<20%.
23-66 Reset Continuous Bin Data
Option: Function:
[0] * Do not reset
Select [1]
Do reset
to reset all values in
23-61 Continuous Bin Data. After pressing [OK]
the setting of the parameter value will
automatically change to [0] Do not reset.
[1] Do reset
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
148 MG16H102 - VLT
®
is a registered Danfoss trademark
33
