Danfoss VLT FC 103 Programming Guide

13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[37] Digital input DI32 Use the value of DI32 in the logic rule
(High
= TRUE).
[38] Digital input DI33 Use the value of DI33 in the logic rule
(High
= TRUE).
[39] Start command This logic rule is TRUE if the frequency
converter
is started by any means
(either via digital input, field bus or
other).
[40] Drive stopped This logic rule is TRUE if the frequency
converter
is stopped or coasted by any
means (either via digital input, fieldbus
or other).
[41] Reset Trip This logic rule is TRUE if the frequency
converter
is tripped (but not trip-
locked) and [Reset] is pressed.
[42] Auto Reset Trip This logic rule is TRUE if the frequency
converter
is tripped (but not trip-
locked) and an Automatic Reset is
issued.
[43] OK Key This logic rule is TRUE if the OK key on
the
LCP is pressed.
[44] Reset Key This logic rule is TRUE if the Reset key
on
the LCP is pressed.
[45] Left Key This logic rule is TRUE if the Left key
on
the LCP is pressed.
[46] Right Key This logic rule is TRUE if the Right key
on
the LCP is pressed.
[47] Up Key This logic rule is TRUE if the Up key on
the
LCP is pressed.
[48] Down Key This logic rule is TRUE if the Down key
on
the LCP is pressed.
[50] Comparator 4 Use the result of comtor 4 in the logic
rule.
[51] Comparator 5 Use the result of comtor 5 in the logic
rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic
rule.
[61] Logic rule 5 Use the result of logic rule 5 in the
logic
rule.
[70] SL Time-out 3 Use the result of timer 3 in the logic
rule.
[71] SL Time-out 4 Use the result of timer 4 in the logic
rule.
[72] SL Time-out 5 Use the result of timer 5 in the logic
rule.
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[73] SL Time-out 6 Use the result of timer 6 in the logic
rule.
[74] SL Time-out 7 Use the result of timer 7 in the logic
rule.
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
13-41 Logic Rule Operator 1
Array [6]
Option: Function:
Select the first logical operator to use on
the
Boolean inputs from 13-40 Logic Rule
Boolean 1 and 13-42 Logic Rule Boolean 2.
[13-**] signifies the boolean input of
parameter group 13-**.
[0] * DISABLED
Ignores 13-42
Logic Rule Boolean 2,
13-43 Logic Rule Operator 2, and 13-44 Logic
Rule Boolean 3.
[1] AND Evaluates the expression [13-40] AND
[13-42].
[2] OR Evaluates the expression [13-40] OR [13-42].
[3] AND NOT Evaluates the expression [13-40] AND NOT
[13-42].
[4] OR NOT Evaluates the expression [13-40] OR NOT
[13-42].
[5] NOT AND Evaluates the expression NOT [13-40] AND
[13-42].
[6] NOT OR Evaluates the expression NOT [13-40] OR
[13-42].
[7] NOT AND NOT Evaluates the expression NOT [13-40] AND
NOT
[13-42].
[8] NOT OR NOT Evaluates the expression NOT [13-40] OR
NOT
[13-42].
13-42 Logic Rule Boolean 2
Array [6]
Option: Function:
Select the second boolean (TRUE or
FALSE)
input for the selected logic
rule.
See 13-40 Logic Rule Boolean 1 for
further descriptions of choices and
their functions.
[0] * False
[1] True
[2] Running
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
MG16H102 - VLT
®
is a registered Danfoss trademark
89
3 3
