Danfoss VLT Micro Drive FC 51 Operating Instructions

Control card, 10 V DC output:
Terminal number 50
Output voltage 10.5 V ±0.5 V
Max. load 25 mA
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage
terminals.
Surroundings:
Enclosure IP 20
Enclosure kit available IP 21
Enclosure kit available TYPE 1
Vibration test 1.0 g
Max. relative humidity 5% - 95%(IEC 60721-3-3; Class 3K3 (non-condensing) during operation
Aggressive environment (IEC 60721-3-3), coated class 3C3
Test method according to IEC 60068-2-43 H2S (10 days)
Ambient temperature Max. 40 °C
Derating for high ambient temperature, see section on special conditions
Minimum ambient temperature during full-scale operation 0 °C
Minimum ambient temperature at reduced performance - 10 °C
Temperature during storage/transport -25 - +65/70 °C
Maximum altitude above sea level without derating 1000 m
Maximum altitude above sea level with derating 3000 m
Derating for high altitude, see section on special conditions
EMC standards, Emission EN 61800-3, EN 61000-6-3/4, EN 55011, IEC 61800-3
EMC standards, Immunity
EN 61800-3, EN 61000-6-1/2, EN 61000-4-2, EN 61000-4-3,
EN 61000-4-4, EN 61000-4-5, EN 61000-4-6
See section on special conditions
7.3. Special Conditions
7.3.1. The Purpose of Derating
Derating must be taken into account when using the frequency converter at low air pressure
(heights), at low speeds or at high ambient temperature. The required action is described in this
section.
7.3.2. Derating for Ambient Temperature
The ambient temperature measured over 24 hours should be at least 5 °C lower than the max.
ambient temperature.
If the frequency converter is operated at high ambient temperature, the continuous output current
should be decreased.
The VLT Micro Drive FC 51 has been designed for operation at max 50 °C ambient temperature
with one motor size smaller than nominal. Continuous operation at full load at 50 °C ambient
temperature will reduce the lifetime of the frequency converter.
7.3.3. Derating for Low Air Pressure
The cooling capability of air is decreased at low air pressure.
VLT Micro Drive FC 51 Operating Instructions 7. Specifications
MG.02.A2.02 - VLT
®
is a registered Danfoss trademark 33
7
