1.1.8.
Before Commencing Repair Work
1.
Disconnect FC 51 from mains (and external DC supply, if
present.)
2.
Wait for 4 mi
nutes for
discharge of the DC-link.
3.
Disconnect DC bus terminals
and brake terminals (if present)
4.
Remo
ve motor
cabl
e
VLT Micro Drive FC 51 Operating Instructions
1. Safety
MG.02.A2.02 -
VLT
®
is a registered Da
nfoss trademark
5
1
4
6
Table of Contents
