e30bg831.10
Illustration 29: The MCB 159 Installed
4.2.4.1 Connecting a VLT® Sensorless Safety MCB 159 (MCB 151 Only)
Procedure
1. Connect the cable marked TER4:ENC A on the MCB 159 to terminal 4 on the MCB 151.
e30bg837.10
A
24 V
4
10
11GND
FC 302
MCB 151
MCB 159
Installation
Installation Guide | VLT® Safety Option MCB 150/151
AQ279747441421en-000101 / 130R0292
48 | Danfoss A/S © 2018.09
