VLT is a registered Danfoss trademark
9-1
Spares Common to All Drive Sizes and Voltages
SPARE,PCA,CONTROL,VLT5000P
Control PCA - VLT 5000 Process
PCA1 176F1452 SPARE,CTRL CARD ASSY,PROC,CONF Control PCA - VLT 5000 Process. Conformal coated
SPARE,PCA,CTRL CARD,VLT6000
Control PCA - VLT 6000 HVAC
PCA1 176F1453 SPARE,CTRL CARD,AQUA/HVAC,CONF Control PCA - VLT 6000 HVAC. Conformal coated
SPARE,PCA,CONTROL,VLT4000V
PCA1 176F5592 SPARE,PCA,CONTROL,VLT4000V,COAT Control PCA - VLT 4000. Conformal coated
SPARE,CONTROL,FLUX UNIT W/SOFTWARE,C1
Control PCA - VLT 5000 Flux. Conformal coated
PCA1 176F5580 SPARE,PCA,CONTROL,8000A Control PCA - VLT 8000 Aqua
SPARE,CONTROL CARD,VLT8000A,COATED
Control PCA - VLT 8000 Aqua. Conformal coated
LCP1 175Z0401 SPARE,LOCAL CONTROL PANEL,PROC LCP - Process
SPARE,LOCAL CONTROL PANEL,HVAC
PCA1 MK100 613X6358 SPARE,CC CONNECTOR,12 POS
Controll card 12 position terminal block connector
Controll card 3 position terminal block connector
PCA1 MK101 613X6359 SPARE,CC CONNECTOR,9 POS
Controll card 9 position terminal block connector
PCA1 175Z1064 SPARE.CONTROL CARD CASSETTE Control card cassette
Spare Parts List
Common Spares for All Models
General Notes:
IGBT spare part kits for D1 and D2 380-500 VAC units include the IGBT modules requir
ed to replace
all modules in the drive, along with the gate cables. For all other units, the IGBT spare part kits have
just one IGBT module, and gate cables must be ordered separately.
The IGBT mounting procedure has changed from thermal grease application to use of thermal
mounting pads. Replacement parts now come with thermal pads. Thermal grease is permitted for
existing spare parts in inventory.
For 600/690 VAC units, use only the wire harness dated after 18 April 2005. For 380-500 V
AC drives,
either the new or older wire harness may be used. The date of the spare is shown on the spare part
kit.
When ordering spare parts for conformal coated drives, choose the appropriate conformal coated
version of the control card and power card. All other spare parts are suitable for conformal coated
drives and can be used in either coated or non-conformal coated drives.
Bus bars used in some units are aluminum. Spare part bus bars are always plated copper
. Plated
copper bus bars are useable for all units.
