3.5 Receiving and Unpacking the Unit
3.5.1 Unpacking
NOTICE
Before unpacking the VLT
®
Plus Panel, place the unit as
close as possible to the nal installation site. Refer to
chapter 3.5.3 Lifting the Unit.
Remove the box and handle the VLT
®
Plus Panel on the
pallet as long as possible.
The VLT
®
Plus Panel shipment consists of:
•
Panels.
•
Documentation package in the enclosure.
•
Pedestal.
•
Accessory bag.
•
Installation guide.
•
Make sure that the items supplied and the
information on the nameplate correspond to the
order conrmation.
•
Visually check the packaging and the VLT
®
Plus
Panel for damage caused by inappropriate
handling during shipment. File any claim for
damage with the carrier. Retain damaged parts
for
clarication.
NOTICE
LOSS OF WARRANTY
Removing the nameplate from the VLT
®
Plus Panel can
result in loss of warranty.
3.5.2 Tools Needed
Receiving/Unloading
•
I-beam and hooks rated to lift minimum the
weight given in the shipping documents
accompanying the VLT
®
Plus Panel.
•
Crane or other lifting aid to place the unit into
position.
•
Crowbar to disassemble the wooden shipping
container (if shipped in such).
Installation
•
Drill with 10 mm or 12 mm drill bits.
•
Tape measure.
•
Screwdriver.
•
Wrench with relevant metric sockets (7–17 mm).
•
Wrench extensions.
•
Sheet metal punch for conduits or cable glands.
•
Lifting aid rated to lift minimum weight given in
the documentation package supplied with the
VLT
®
Plus Panel. See chapter 5.3 Weights, and
chapter 3.5.3 Lifting the Unit.
•
Crane or other lifting aid to place the unit onto
pedestal and into position.
•
Torx T50 tool.
Mechanical Installation Installation Guide
