Danfoss VLT series Installation Guide

1 Introduction
1.1 Purpose of the Manual
This installation guide provides information for safe instal-
lation of the VLT
®
Plus Panel.
The dedicated documentation set of each VLT
®
Plus Panel
provides all information for connecting conditions,
maximum cross-sections of mains/motor cables, and so on.
NOTICE
The documentation set is specic per order. The shown
values in this manual provide average data.
The installation guide is intended for use by qualied
personnel.
Read and follow the installation guide to use the VLT
®
Plus
Panel safely and professionally. Pay particular attention to
the safety instructions and general warnings. Incorrect
handling of the VLT
®
Plus Panel may cause improper
operation of the frequency converter or related equipment,
shorten lifetime, or cause other troubles. Always keep this
installation guide available with the VLT
®
Plus Panel.
VLT
®
is a registered trademark.
This manual is structured in the following way:
•
Chapter 1 Introduction introduces the manual and
informs about approvals, symbols, and abbrevi-
ations used in this manual.
•
Chapter 2 Safety entails instructions on how to
handle the VLT
®
Plus Panel in a safe way.
•
Chapter 3 Mechanical Installation and
Chapter 4 Electrical Installation guide through the
mechanical and electrical installation.
•
Chapter 5
Specications contains technical data
about the VLT
®
Plus Panel.
•
An alphabetical index concludes the manual.
1.2
Additional Resources
Additional information on the VLT
®
Plus Panel can be
found in the enclosure door pocket:
•
Documentation for all components of the VLT
®
Plus Panel
•
Wiring diagrams
•
Test certicates from unit assembly
•
EC declaration of conformity
All information related to the frequency converter is not
part of this manual and provided via the separate
documentation for the dierent frequency converters:
•
The Operating Instructions provide detailed
information for the installation and start-up of the
frequency converter. This manual is provided with
the VLT
®
Plus Panel documentation set.
•
The Design Guide entails all technical information
about the frequency converter and customer
design and applications.
•
The Programming Guide provides information on
how to programme and includes complete
parameter descriptions.
•
Manuals for frequency converter options are
listed in the documentation for the frequency
converter. Operating Instructions or Installation
Instructions for the built-in options are provided
with the VLT
®
Plus Panel documentation set.
Danfoss technical literature is also available online at vlt-
drives.danfoss.com/support/technical-documentation/.
1.3
Document Version
This manual is regularly reviewed and updated. All
suggestions for improvement are welcome. Table 1.1 shows
the document version.
Edition Remarks
MG13B1xx Initial creation
Table 1.1 Document Version
Introduction Installation Guide
MG13B102 Danfoss A/S © 09/2015 All rights reserved. 3
1 1

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
