Danfoss VLT series - Mechanical Installation

F
1
F
2
130BE485.10
F: Weight force
Illustration 3.4 Crane Transport of a Double Enclosure (Full Weight Force on Central Lifting Cable)
F
F
3
2
1
F
130BE486.10
F: Weight force
Illustration 3.5 Crane Transport of a Triple Enclosure (Full Weight Force on Central Lifting Cable)
Mechanical Installation
VLT
®
Plus Panel
