Danfoss VLT series

3.2.4.8 Options Cabinet, Enclosure Sizes F11 and F13
4
316.4 179.2 135.2
80.4 36.4
.0
244.4
.0
151.3
440.4
547.8
.0
73.0 88.1
112.0 138.9 172.0 180.7 232.0 231.5 273.3 324.1 338.9 387.8 437.0 438.6 480.4 497.0 531.2 557.0 573.0 602.3 625.8
130BB757.11
1
2
3
1 Left side view
2 Front view
3 Right side view
4 Ground bar
Illustration 3.20 Terminal Locations Options Cabinet, Enclosure Sizes F11 and F13
How to Install Operating Instructions
MG34Q402 Danfoss A/S © 04/2016 All rights reserved. 27
3 3
