3.4.14 Supplementary Fuses
Size/type Bussmann PN Rating Alternative fuses
2.5–4.0 A fuse P450–P800, 380–500 V LPJ-6 SP or SPI 6 A, 600 V Any listed Class J Dual
Element, Time Delay, 6 A
P630–P1M8, 525–690 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
4.0–6.3 A fuse P450–P800, 380–500 V LPJ-10 SP or SPI 10 A, 600 V Any listed Class J Dual
Element, Time Delay, 10 A
P630–P1M8, 525–690 V LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
6.3–10 A fuse P450–P800, 380–500 V LPJ-15 SP or SPI 15 A, 600 V Any listed Class J Dual
Element, Time Delay, 15 A
P630–P1M8, 525–690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual
Element, Time Delay, 20 A
10–16 A fuse P450–P800, 380–500 V LPJ-25 SP or SPI 25 A, 600 V Any listed Class J Dual
Element, Time Delay, 25 A
P630–P1M8, 525–690 V LPJ-20 SP or SPI 20 A, 600 V Any listed Class J Dual
Element, Time Delay, 20 A
Table 3.20 Manual Motor Controller Fuses
Enclosure size Bussmann PN Rating
F8–F15 KTK-4 4 A, 600 V
Table 3.21 SMPS Fuse
Size/type Bussmann PN LittelFuse Rating
P315–P800,
380–500 V
– KLK-15 15 A, 600 V
P500–P1M8,
525–690 V
– KLK-15 15 A, 600 V
Table 3.22 Fan Fuses
Enclosure
size
Bussmann PN Rating
Alternative
fuses
F8–F15 LPJ-30 SP or
SPI
30 A, 600 V Any listed
Class J Dual
Element, Time
Delay, 30 A
Table 3.23 30 A Fuse Protected Terminal Fuse
Enclosure
size
Bussmann PN Rating
Alternative
fuses
F8–F15 LPJ-6 SP or SPI 6 A, 600 V Any listed
Class J Dual
Element, Time
Delay, 6 A
Table 3.24 Control Transformer Fuse
Enclosure size
Bussmann PN Rating
F8–F15 GMC-800MA 800 mA, 250 V
Table 3.25 NAMUR Fuse
Enclosure
size
Bussmann PN Rating
Alternative
fuses
F8–F15 LP-CC-6 6 A, 600 V Any listed
Class CC, 6 A
Table 3.26 Safety Relay Coil Fuse with Pilz Relay
Enclosure
size
Power Type
380–500 V
F9 P250 ABB OETL-NF600A
F9 P315 ABB OETL-NF600A
F9 P355 ABB OETL-NF600A
F9 P400 ABB OETL-NF600A
F11 P450 ABB OETL-NF800A
F11 P500 ABB OETL-NF800A
F11 P560 ABB OETL-NF800A
F11 P630 ABB OT800U21
F13 P710 Merlin Gerin NPJF36000S12AAYP
F13 P800 Merlin Gerin NPJF36000S12AAYP
525–690 V
F9 P355–P560 ABB OT400U12-121
F11 P630–P710 ABB OETL-NF600A
F11 P800 ABB OT800U21
F13 P900 ABB OT800U21
F13 P1M0–P1M2 Merlin Gerin NPJF36000S12AAYP
F15 P1M4–P1M8 Merlin Gerin NPJF362000S20AAYP
Table 3.27 Mains Disconnectors
How to Install
VLT
®
AutomationDrive FC 302
50 Danfoss A/S © 04/2016 All rights reserved. MG34Q402
