Danfoss VLT series User Manual

Power size Enclosure Rating Bussmann
Spare
Bussmann
Estimated fuse power loss [W]
FC 302 Type [V] (UL) [A] P/N P/N 400 V 460 V
P250T5 F8/F9 700 700 170M4017 176F8591 25 19
P315T5 F8/F9 700 700 170M4017 176F8591 30 22
P355T5 F8/F9 700 700 170M4017 176F8591 38 29
P400T5 F8/F9 700 700 170M4017 176F8591 3500 2800
P450T5 F10/F11 700 900 170M6013 176F8592 3940 4925
P500T5 F10/F11 700 900 170M6013 176F8592 2625 2100
P560T5 F10/F11 700 900 170M6013 176F8592 3940 4925
P630T5 F10/F11 700 1500 170M6018 176F8592 45 34
P710T5 F12/F13 700 1500 170M6018 176F9181 60 45
P800T5 F12/F13 700 1500 170M6018 176F9181 83 63
Table 3.16 Mains Fuses, 380–500 V
Power size Enclosure Rating Bussmann
Spare
Bussmann
Estimated fuse power loss [W]
FC 302 Type [V] (UL) [A] P/N P/N 600 V 690 V
P355T7 F8/F9 700 630 170M4016 176F8335 13 10
P400T7 F8/F9 700 630 170M4016 176F8335 17 13
P500T7 F8/F9 700 630 170M4016 176F8335 22 16
P560T7 F8/F9 700 630 170M4016 176F8335 24 18
P630T7 F10/F11 700 900 170M6013 176F8592 26 20
P710T7 F10/F11 700 900 170M6013 176F8592 35 27
P800T7 F10/F11 700 900 170M6013 176F8592 44 33
P900T7 F12/F13 700 1500 170M6018 176F9181 26 20
P1M0T7 F12/F13 700 1500 170M6018 176F9181 37 28
P1M2T7 F12/F13 700 1500 170M6018 176F9181 47 36
P1M4T7 F14/F15 700 2000 170M7082 176F8769 25 25
P1M6T7 F14/F15 700 2000 170M7082 176F8769 25 29
P1M8T7 F14/F15 700 2000 170M7082 176F8769 25 29
Table 3.17 Mains Fuses, 525–690 V
Size/Type
Bussmann PN
1)
Rating Siba
P450 170M8611 1100 A, 1000 V 20 781 32.1000
P500 170M8611 1100 A, 1000 V 20 781 32.1000
P560 170M6467 1400 A, 700 V 20 681 32.1400
P630 170M6467 1400 A, 700 V 20 681 32.1400
P710 170M8611 1100 A, 1000 V 20 781 32.1000
P800 170M6467 1400 A, 700 V 20 681 32.1400
Table 3.18 Inverter Module DC-Link Fuses, 380–500 V
Size/Type
Bussmann PN
1)
Rating Siba
P630–P1M8 170M8611 1100 A, 1000 V 20 781 32. 1000
Table 3.19 Inverter Module DC-Link Fuses, 525–690 V
1) The Bussmann 170M fuses shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110. Type T indicator fuses of the same size and
amperage may be substituted for external use.
How to Install Operating Instructions
MG34Q402 Danfoss A/S © 04/2016 All rights reserved. 49
3 3
