Danfoss VLT series

130BE179.10
1282.8 (50.50)
50.1 (1.97)
525.6
(20.69)
220.7
(8.69)
276.6
(10.89)
62.8 (2.47)
760.6 (29.95)
800.0 (31.50)
3498.9 (137.75)
62.8 (2.47)
460.0 (18.11) 593.0 (23.35) 206.0 (8.11)
84.8 (3.34)
62.8 (2.47)
149.5 (5.89)
49.5 (1.95)
199.5
(7.85)
75.1(2.96)
200 (7.87)
176.2 (6.94)
82.8 (3.26)
226.8 (8.93)
635.1 (25.00)
435.0
(17.13)
1201.0 (47.28)
18.2 (0.72)
600.0 (23.62)
560.6 (22.07)
Illustration 3.31 F15, Cable Entry Viewed from the Bottom of the Frequency Converter
How to Install Operating Instructions
MG34Q402 Danfoss A/S © 04/2016 All rights reserved. 33
3 3
