Number Text
516 Cannot write to the EEPROM because a write
command is in progress.
517 The write command is under timeout.
518 Failure in the EEPROM.
519 Missing or invalid barcode data in EEPROM.
783 Parameter value outside of minimum/maximum
limits.
1024–1279 A CAN telegram could not be sent.
1281 Digital signal processor ash timeout.
1282 Power micro software version mismatch.
1283 Power EEPROM data version mismatch.
1284 Cannot read digital signal processor software
version.
1299 The option software in slot A is too old.
1300 The option software in slot B is too old.
1301 The option software in slot C0 is too old.
1302 The option software in slot C1 is too old.
1315 The option software in slot A is not supported (not
allowed).
1316 The option software in slot B is not supported (not
allowed).
1317 The option software in slot C0 is not supported
(not allowed).
1318 The option software in slot C1 is not supported
(not allowed).
1379 Option A did not respond when calculating the
platform version.
1380 Option B did not respond when calculating the
platform version.
1381 Option C0 did not respond when calculating the
platform version.
1382 Option C1 did not respond when calculating the
platform version.
1536 An exception in the application-oriented control is
registered. The debug information is written on
the LCP.
1792 DSP watchdog is active. Debugging of power part
data, motor-oriented control data not transferred
correctly.
2049 Power data restarted.
2064–2072 H081x: Option in slot x has restarted.
2080–2088 H082x: Option in slot x has issued a power-up
wait.
2096–2104 H983x: Option in slot x has issued a legal power-
up wait.
2304 Could not read any data from the power EEPROM.
2305 Missing software version from the power unit.
2314 Missing power unit data from the power unit.
2315 Missing software version from the power unit.
2316 Missing lo_statepage from the power unit.
2324 The power card conguration is determined to be
incorrect at power-up.
2325 A power card has stopped communicating while
mains power is applied.
Number Text
2326 The power card conguration is determined to be
incorrect after the delay for power cards to
register.
2327 Too many power card locations have been
registered as present.
2330 The power size information between the power
cards does not match.
2561 No communication from DSP to ATACD.
2562 No communication from ATACD to DSP (state
running).
2816 Stack overow control board module.
2817 Scheduler slow tasks.
2818 Fast tasks.
2819 Parameter thread.
2820 LCP stack overow.
2821 Serial port overow.
2822 USB port overow.
2836 cfListMempool is too small.
3072–5122 The parameter value is outside its limits.
5123 Option in slot A: Hardware incompatible with the
control board hardware.
5124 Option in slot B: Hardware incompatible with the
control board hardware.
5125 Option in slot C0: Hardware incompatible with the
control board hardware.
5126 Option in slot C1: Hardware incompatible with the
control board hardware.
5376–6231 Out of memory.
Table 6.1 Internal Fault, Code Numbers
ALARM 39, Heat sink sensor
No feedback from the heat sink temperature sensor.
The signal from the IGBT thermal sensor is not available on
the power card. The problem could be on the power card,
on the gatedrive card, or the ribbon cable between the
power card and gatedrive card.
WARNING 40, Overload of digital output terminal 27
Check the load connected to terminal 27 or remove the
short circuit connection. Check parameter 5-00 Digital I/O
Mode and parameter 5-01 Terminal 27 Mode.
WARNING 41, Overload of digital output terminal 29
Check the load connected to terminal 29 or remove the
short circuit connection. Also check parameter 5-00 Digital
I/O Mode and parameter 5-02 Terminal 29 Mode.
WARNING 42, Overload of digital output on X30/6 or
overload of digital output on X30/7
For terminal X30/6, check the load connected to terminal
X30/6 or remove the short circuit connection. Also check
parameter 5-32 Term X30/6 Digi Out (MCB 101) (VLT
®
General Purpose I/O MCB 101).
For terminal X30/7, check the load connected to terminal
X30/7 or remove the short circuit connection. Check
Warnings and Alarms
VLT
®
AutomationDrive FC 302
88 Danfoss A/S © 04/2016 All rights reserved. MG34Q402
6
6

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
