DataCard SD260 Installation And Administration Guide

A-6 SD460 Laminating System
Assemble the Printer and Laminator
1. Locatetheinterconnectcableinthe
cableroutingareaofthelaminator
andmakesurethatitremains
accessible.
2. Openthelaminatoraccessdoor.
3. Slidetheprinterlockingleverinthe
laminatortothelefttopositionthe
mountinglockintheunlocked
state.
4. Lifttheprinteroverthelaminator
andalignthepinsonthelaminatorwiththe
holesontheundersideoftheprinter.
5. Pressdownontheprintercarefully,butfirmly,
topositionit.
6. Pushtheprinterlockinglevertotherightto
locktheprinterontothelaminator.Makesure
thattheprinterissecurelylockedtothe
laminator.
7. Closethelaminatoraccessdoor.
Interconnect
Cable
Lock
Unlock
Printer Locking
Lever

DataCard SD260 Specifications

General

Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Color	Yes
Print speed (color)	200 card/h
Product color	Blue, Grey

Weight and Dimensions

Depth	391 mm
Width	175 mm
Height	224 mm
