8 Installation
Install Optional Equipment
Youcaninstalladditionalequipmentontheprinte r dependingonyour
requirements.
Install a Large Output Hopper
Theoutputhopperincludedwiththeprinterholdsabout250.030in.(0.762mm)
cards.Theprinteralsocanbeusedwithanoptionallargeoutputhopper that
holdsupto100cards.
Thelargeoutputhopperkitincludestwobasesectionsandthelargeoutput
hopper.Thetwobasesectionsareidentical,withhooks(markedbygreencircles)
thatattachtothebottomoftheprinter.Toassemblethebase,arr angethebase
sectionsbacktoback,asshown.
Youcanremovethestandardhopperandattachthelargeoutputhopperwithout
usingtools.
YoucannotinstallthelargeoutputhopperontheSD460system.A100‐card
laminatoroutputhopperisstandardontheSD460system.
Base Sections
Large Output
Hopper
