DataCard SD260 Installation And Administration Guide

SD Series Installation and Administrator’s Guide 9
Dothefollowing toattachtheprintertothebases,andtoinstallthelargeroutput
hopper.Youalsocanrefertotheinstructionsshippedwiththelargeoutput
hopperkit.
1. Positiononebasesectionwiththeopenendfacingthebackoftheprinter.
2. Lifttheprinteroverthebasesection.
3. Alignthetabsinthebasewiththeslotsinthebottomoftheprinter.
4. Pushuptoinsertthefourtabsintheslots,andthenpushthebaseforwardto
lockittotheprinter.
5. Positiontheotherbasesectionwiththeopeningfacingthefrontofthe
printer.
6. Pushuptoinsertthefourtabsintheslotsandthenpushthebasebacktolock
ittotheprinter.
7. Removethe25‐cardoutputhopperfromtheprinter.Slideitout,similartoa
drawer.
8. Slidethe100‐cardoutputhopperintotheassembledbaseandprinter.Make
surethatthetabs(shownincirclesintheillustration)securethehopperto
theprinter.
HINTS&TIPS
• Thebasesectionscontaindrawers,usefulforholdingcards,cleaningswabs,
orotherfrequentlyuseditems.Thedrawerscanbeopenedfromeitherthe
leftorrightsideoftheprinter.
• Thebaseand largeoutputhopperremainattachedwhentheprinterismoved
orcarried.
Ifyouinstallthe100‐cardoutputhopper,changethePrinterManagerPrinter
Setting>TransportEjectHopperSpeedsettingtoehs_Extended.Thisallows
completedcardstostackproperlyinthelargeroutputhopper.Referto“Transport ”
onpage51 forcompleteinformation.

DataCard SD260 Specifications

General

Windows operating systems supported	Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Color	Yes
Print speed (color)	200 card/h
Product color	Blue, Grey

Weight and Dimensions

Depth	391 mm
Width	175 mm
Height	224 mm
