SD260L/SD360/SD460 Installation and Administrator’s Guide 99
Optional Equipment
The following optional equipment is available.
Large Output Hopper
The printer can use a large output hopper, which holds about
100 cards. You can replace the small, standard hopper with the
large hopper without using tools.
200-Card Input Hopper
The 200-card input hopper kit includes the larger hopper with an attached cover. The standard
hopper is easily removed and the 200-card hopper can be installed without using tools.
Cable Lock
The printer can be used with a cable lock. Obtain the lock from your dealer, because it includes an
added security plate that is inserted into the printer.

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
