DataCard SD460 Installation And Administrator's Guide

SD260L/SD360/SD460 Installation and Administrator’s Guide 73
LaminateType
Use the LaminateType options to specify settings for the overlay materials used in the laminating
system.
Description
Default
Value
Current Value
(unit) Allowed Range
1) DatabaseVersion 1 13 [1 – 999]
2) ExclusiveOverlayInL1 Disabled
3) ExclusiveOverlayInL2 Disabled
4) OverlayDisplayed Name 0.5_mil_Clear_DG
5) OverlayLoadedInL1 Name 0.5_mil_Clear_DG
6) OverlayLoadedInL2 Name Clear_Topcoat
OverlayPartNumber 0 509065
OverlaySpeed 160 160 [100 – 250]
OverlaySpeed AdjustmentL1 0 0 [-40 – 40]
OverlaySpeed AdjustmentL2 0 0 [-40 – 40]
OverlayTemp 160 175 [100 – 200]
OverlayTemp AdjustmentL1 0 15 [-20 – 40]
OverlayTemp AdjustmentL2 0 0 [-20 – 40]
UserOverlay1Name None
UserOverlay2Name None
UserOver3Name None
UserOverlay4Name None

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
