SD260L/SD360/SD460 Installation and Administrator’s Guide A-5
Bolt-Down Option
The laminator includes bolt-down openings that you can use to secure the system to a mounting
surface.
You need the following supplies:
 The bolt-down kit (part no. 509169-001) contains two M6 well nuts.
 Two M6 (6 mm) screws, purchased separately.
The length of the screws you need depends on the thickness of the mounting surface. The
screw length is the surface thickness + 0.75 inch (20 mm).
 Two M6 washers, purchased separately.
 1/4-inch (7 mm) drill bit.
1. Drill two holes in the mounting surface following the dimensions and requirements shown in
the following figure:
This procedure is optional.

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
