DataCard SD460 Installation And Administrator's Guide

A-4 SD460 Laminating System
Unpack the System
Remove the printer and laminator from their shipping cartons.
1. Open the printer shipping carton and remove the printer and its accessories.
2. Open the laminator shipping carton and remove the accessories boxes.
3. Lift the laminator from the carton and remove the foam end caps.
4. Place the laminator on a surface that meets the requirements specified in “SD460 Site
Requirements” on page A-2.
5. Secure the laminator, if necessary. Refer to “Bolt-Down Option” on page A-5.
Save the shipping cartons and packing materials. They are required if you need to
store, move, or return the system for service.
Laminator
Power Supplies
and Cords
Packing Materials
(foam end caps)

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
