DataCard SD460 Installation And Administrator's Guide

44 Printer Manager
Printer Setting Menu
Use the Printer Setting menu to view and customize printer settings.
Printer Setting Menu
Option Function WebUser WebAdmin
Communication Set or view the network
address method used by the
printer.
No Change Current
Values
ActivityLog Set values in the activity log
to help isolate card
production issues.
No Change all
Current Values
Behavior Display printer operation and
control methods.
Change
RibbonInitialize
Change all
Current Values
VitalProductData Change printer information.
Available to WebService
access level users only.
No No
FrontPanel Set front panel values for the
printer.
Change Backlight
Brightness,
KeySenseLevel and
SpeakerEnabled
values
Change all
Current Values

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
