DataCard SD460 Installation And Administrator's Guide

SD260L/SD360/SD460 Installation and Administrator’s Guide A-3
Clearance Requirements
The following measurements show the system dimensions when the input hopper, printer cover,
and laminator access doors are open.
SD460 Electrical Requirements
The power supply is rated as follows:
We recommend that you provide a minimum of 3 inches (76.2 mm) of additional
clearance around the system to maintain access to the power cord and data cables,
to load and remove cards and supplies, and to provide ventilation.
System Component
Electrical Requirements
Input Output
Printer 110–240V/50–60 Hz/1.5 Amp 24V/3.0Amp/72W
Laminator with L1 only 100–240V/47–63 Hz/2.2 Amp 24V/3.75Amp/90W
Laminator with L1, L2,
and impresser
100–240V/47–63 Hz/2.2 Amp 24V/6.6Amp/160W
9.0 in
229 mm
25.5 in
648 mm
23.6 in
600 mm
26.1 in / 663 mm
29.5 in / 749 mm
(with impresser)
11.4 in
290 mm
19.6 in
498 mm
3.1 in
79 mm

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
