DataCard SD460 Installation And Administrator's Guide

SD260L/SD360/SD460 Installation and Administrator’s Guide 3
Site Requirements
Set up and use the printer in an environment that meets the following requirements.
 Place the printer in an environment with temperatures ranging from 60° to 95°F (15° to 35°C).
 Use a single-phase, 3-wire, grounded receptacle.
 Place the printer and its supplies in a clean office environment, keeping paper and foreign
materials off of the equipment.
 Place the printer in a location that provides the following:
 A sturdy, level surface. Avoid unstable locations.
 A surface that allows easy user access. Refer to “Printer Dimensions” for more
information.
 Enough space to open all printer doors and to access power cords and data cables. Refer
to “Clearance Requirements” on page 4.
 Enough space around the printer to allow for ventilation.
 Place the printer away from direct sunlight.
 Do not place the printer near heating ducts, fans, or other air vents.
 Do not use the printer for purposes other than the intended use.
Printer Dimensions
The external printer dimensions are shown in the following illustration.
8.8 in
224 mm
6.87 in
174 mm
21.2 in
539 mm

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
