DataCard SD460 Installation And Administrator's Guide

SD260L/SD360/SD460 Installation and Administrator’s Guide 43
Audit Data Display card printer usage data,
including card counts (both
resettable—shown with an r as the
first letter of the name—and non-
resettable counts) and error
reporting collected by the printer.
This page acts as a general overview
for all the counters and can be
useful to track card production
activity and problem history.
View View
Adapters Display information about the
IP addresses configured for the
printer. The printer can have an IPv4
address and multiple IPv6 addresses
configured concurrently. The page
shows the IP address, network mask
(or IPv6 prefix), gateway address,
and MAC address for each adapter.
View View
About Printer Manager Display the Printer Manager
software version and copyright
information.
View View
Status Menu Option Function WebUser WebAdmin

DataCard SD460 Specifications

General

Color	Yes
Card size	85.6 x 53.98 mm
Card types	Magnetic stripe (ISO 7811), PVC, Smart card
Print technology	Dye-sublimation/Resin Thermal transfer
Duplex print speed (color)	200 card/h
Display	LCD
Certification	cULus, FCC, I.C., CE, Ctick, VCCI, RoHS, WEEE, CCC, KCC
Product color	Black, Blue
Internal memory	128 MB
Built-in barcodes	1D, 2D
Total input capacity	100 sheets
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Wi-Fi	No
USB version	2.0
Ethernet interface type	Fast Ethernet
Storage temperature (T-T)	-15 - 60 °C
Operating temperature (T-T)	15 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	13600 g
Dimensions (WxDxH)	589 x 270 x 513 mm
