SR200 & SR300 Card Printers and LM200 & LM300 Laminators User’s Guide 31
 SpecifytheMACaddressposition.WhenusingtheUVpanel,theMACaddressoftheprinter
isalwaysprintedonthecardusingtheUVpanel:
 ChoicesareUpperRight(1)andLowerLeft.(2),where(3)isthe
0,0pointofthecardimage.TheMACaddressblockis34pixels
highand230pixelslong.
 Landscape:Theupperrightlocationstartsat764,18.Thelower‐
leftlocationstartsat42,611.
 Portrait:Theupperrightlocationstartsat612,743.Thelower‐left
locationstartsat19,42.
 Specifythenumberofretransferpanelsusedtoprintonesideofa
card(1Panel,2Panels,orAuto).UVandYMCKinkscannotbe
transferredinthesameareaonthesameretransferpanel,sothis
settingdetermineswhatdatawillprint.
Thefollowingtableshowstheresultfor
dataoutsidetheMACaddressareaanddata
overlappingtheMACaddressarea:
PrintingData
SettingforNumberofRetransferFilmPanelsto
Use
1Panel Auto 2Panels
Printingdata
thatoverlaps
withtheUVink
dataoutsidethe
MACaddress
printingarea.
None Printinone
panel
Printinone
panel
Printintwo
panels
YMCInk Printinone
panel(The
YMCinkisnot
printedin
areaswhereit
overlapswith
theUVink.)
Printintwo
panels
Printintwo
panels
KInk Printinone
panel(TheUV
inkisnot
printedin
areaswhereit
overlapswith
theKink.)
Printintwo
panels
Printintwo
panels
