Elrepho 3000
WARNING
The ground circuit for the power outlet must be
continuous to the main power panel which must be
grounded directly to an electrical earth ground.
Improper grounding could result in a shock hazard.
Note also that the Elrepho does not have a user changeable fuse. It
is built into the instrument, and can only be changed by Datacolor
International service personnel.
Dimensions
Both the Elrepho 3100 and 3300 use vertical sample presentation
and have the following dimensions:
Height 14.5"/368mm Width 11.5"/292mm
Depth 18.5"/470mm Weight 31 lbs/14kg
Environmental Requirements
Operating Temperatures: 5-40 degrees C
50-105 degrees F
Relative Humidity (Non-Condensing): 20-85%
Installation
Interconnection and Power Cabling
AC Power Cable
The Elrepho is supplied with a six foot power cable. Power is
applied to the rear of the unit via a three prong male connector.
Datacolor International 7
