Elrepho 3000
This mode is accessed by pressing the soft key labeled CALIB
SETUP in the Setup Mode. The following functions are available
from this mode:
• Select/Edit/Add white standard to use for calibration
• Setting of the recalibration time interval
• Whiteness/UVCAL Setup
Current Calibration Standard
The field labelled STD indicates the name of the white standard
currently used for calibration. This name will be displayed on the
calibration mode screen to indicate the standard to be used during
calibration.
Press SEL to select or add a different calibration standard.
If the desired standard name is not displayed during calibration, you
should not continue with the calibration procedure, and you should
enter the current Calibration Standard Selection Mode to select a
different calibration standard or setup a new calibration standard.
Current Calibration Standard Selection Mode
This mode is entered by pressing SEL while in the Calibration
Setup Mode and the “STD” option is highlighted. When this mode
is entered, a list of currently defined calibration standards are listed.
The Elrepho 3000 series instruments provide support for storing up
to five calibration standards.
Select Standard - To select a calibration standard as the “current”
calibration standard, move the highlight bar to the desired
calibration standard’s “name” and press SEL.
Calibration Setup Mode
Current Calibration Standard Selection Mode (cont)
Datacolor International
33
