Disk Enclosure Cabling
96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 74
Figure 90. SFA12KX/12K-40 Configuration with 2 x SS7000 Enclosures
020 010 012
002
042032 012002
142132 112102
I/O Module A
I/O Module B
Disk Enclosure 01
Controller 0
050040 020010
150140 120110
I/O Module A
I/O Module B
Disk Enclosure 02
032
040 042 050
120
110 112
102
Controller 1
132
140 142
150
No. of HD Mini-SAS to Mini-SAS Cables Required (3-meter): 16
Zoning Configuration: 1
