96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 86
Disk Enclosure Cabling
Figure 102. SFA12KX/12K-40 Configuration with 20 x SS8460 Enclosures
120 121 122 110 112 113 100 101 102 103
Controller 1
075052 065 022
I/O Module A
Disk Enclosure 11
175152 165 122
I/O Module B
075065
I/O Module A
Disk Enclosure 12
175165
I/O Module B
076031 066001
I/O Module A
Disk Enclosure 13
176131 166101
I/O Module B
076066
I/O Module A
Disk Enclosure 14
176166
I/O Module B
077051 067021
I/O Module A
Disk Enclosure 15
177151 167121
I/O Module B
077067
I/O Module A
Disk Enclosure 16
177167
I/O Module B
078033 068003
I/O Module A
Disk Enclosure 17
178133 168103
I/O Module B
078068
I/O Module A
Disk Enclosure 18
178168
I/O Module B
079043 069013
I/O Module A
Disk Enclosure 19
179143 169113
I/O Module B
079069
I/O Module A
Disk Enclosure 20
179169
I/O Module B
020 021 022 010 012 013 000 001 002 003
Controller 0
070032 060002
I/O Module A
Disk Enclosure 01
170132 160102
I/O Module B
070060
I/O Module A
Disk Enclosure 02
170160
I/O Module B
071042 061012
I/O Module A
Disk Enclosure 03
171142 161112
I/O Module B
071061
I/O Module A
Disk Enclosure 04
171161
I/O Module B
072040 062010
I/O Module A
Disk Enclosure 05
172140 162110
I/O Module B
072062
I/O Module A
Disk Enclosure 06
172162
I/O Module B
073050 063020
I/O Module A
Disk Enclosure 07
173150 163120
I/O Module B
073063
I/O Module A
Disk Enclosure 08
173163
I/O Module B
074030 064000
I/O Module A
Disk Enclosure 09
174130 164100
I/O Module B
074064
I/O Module A
Disk Enclosure 10
174164
I/O Module B
No. of HD Mini-SAS to HD Mini-SAS Cables Required:
3-meter: 20
6-meter: 20
3-meter for Enclosure Expansion: 40
150 151 152 140 142 143 130 131 132 133 050 051 052 040 042 043 030 031 032 033
Use 6-meter cables to connect
these ports to the controller
installed in the other rack
Zoning Configuration: 0
