Disk Enclosure Cabling
96-30051-001 Rev. D3 DDN SFA12K (SFA OS 2.3.1) Hardware Installation & Configuration Guide | 96
Figure 112. SFA12KXE/12K-20E Configuration with 3 × SS8460 Enclosures
020 022 010 012 000 002
Controller 0
120 122 110 112 100 102
Controller 1
022000
I/O Module A
Disk Enclosure 03
122100
I/O Module B
020010
I/O Module A
Disk Enclosure 02
120110
I/O Module B
012002
I/O Module A
Disk Enclosure 01
112102
I/O Module B
No. of HD MiniSAS to HD MiniSAS Cables Required (3-meter): 12
Zoning Configuration: 1
