Handbuch Datafox EVO 3.5 Pure Seite 75 Datum: 06.08.2018 Version: 04.03.07.XX
Cable plan for 1 Door, 1 Relayin the EVO 3.5 Pure:
Reader Table, for this example:
ID
ZM / Bus-ID
TM (Busadresse)
RefLocation
RefAction
PinGeneral
description
1
1
010
1
1
0
Reader RS485 Modulplace 1 = Bus ID 1
4
1
320
0
1
0
(Masterdevice)
Recoment wirering for one Bus RS485 with one EVO-Reader-Plus:
Alternate can you use the power from the master device on the RS485 Moduls. Condition is: maxi-
mum one reader in use.
RFID Reader
Type
L in m
current in mA
Strom bei Start in mA
gf. Ergänzungen
Legic
50
iA
iA
Mifare
100
iA
iA
Unique
100
iA
iA
TCP / IP (LAN)
M1
SIM
12VDC
USB
GPRS
GPS
RS232
M7
LAN
M8
485-A
485-B
12V 
GND
M3
M2
DGND
D IN1
Relais
ZK
485-A
485-B
HK
Variante mit RS485 Haupt-
kommunikation
10-30V DC
+ - max. 30V; 2A
Supply for door opener
Bus Nr. 1
EVO-ZK-Leser-Plus
connector 4 poles
for access
control
connector 5 poles
for access
control
RS 485 ZK Bus-ID 1
Bus Nr. 1
Door opener relay on the master device
Supply
12 – 30 V - +
Maximum
recomment length = L
mit 0,25 mm
2
