Handbuch Datafox EVO 3.5 Pure Seite 76 Datum: 06.08.2018 Version: 04.03.07.XX
Cable plan for 3 doors, 3 Relays in the EVO 3.5 Pure:
Reader Table, for this example:
ID
ZM / Bus-ID
TM (Busadresse)
RefLocation
RefAction
PinGeneral
description
1
1
010
1
1
0
reader Bus Nr. 1
2
1
020
2
2
0
readerit Bus Nr. 2
3
1
030
3
3
0
reader Bus Nr. 3
4
1
320
0
1
0
(Master device)
TCP / IP (LAN)
M1
SIM
12VDC
USB
GPRS
GPS
RS232
M7
LAN
M8
485-A
485-B
12V 
GND
M3
M2
DGND
D IN1
Relais
ZK
485-A
485-B
HK
Variante mit RS485 Haupt-
kommunikation
RS 485 ZK
Bus Nr. 1
Door opener relay 1
Supply for door opener
max. 30V; 2A
max.2,5 m
branch box
max.2,5 m
branch box
supply
12 – 30V DC per reader 500mA
max.2,5 m
branch box
Door opener relay 2
Door opener relay 3
Bus Nr. 2
Bus Nr. 3
