K35D03-EN - 118 -
COMMAND
DESCRIPTION
A
NSWER
MODE STOP
Puts the controller into
STOP m
ode. Alarm
s
are also cleared.
MODE AUTO
Puts the controller into
AUTO m
ode. Alarms
are also cleared.
MODE MANUAL
Puts the controller into
MANUAL (RUN)
mode. Alarm
s are also cleared.
MODE TEST
Puts the controller
into TEST
mode. Alarms
are also cleared.
OUT1 ON
Sets remote contro
lled output #1 to acti
ve
state
OUT1 OFF
Sets remote contro
lled output #1 to pass
ive
state
OUTxx ON
Sets remote contro
lled output #xx to ac
tive
state (xx denotes a
ny number between 1 and
16).
OUTxx OFF
Sets remote contro
lled output #xx to pass
ive
state (xx denotes a
ny number between 1 and
16).
OUT xx = OFF
OUT xx = ON
OUT 1 = OFF
OUT 1 = ON
Unit forced to
AUTO!
Unit forced to
STOP!
Unit forced to
TEST!
Unit forced to
RUN!
117
119
Table of Contents
Table of Contents
6
Installation Instructions
10
Mounting
11
Dimensions
11
Sealing, Gasket
14
Electrical Installation
15
Terminal Descriptions
16
Battery Voltage Input
16
Ac Voltage Inputs
17
Ac Current Inputs
18
Digital Inputs
21
Analog Sender Inputs and Sender Ground
21
Charge Input Terminal
22
Magnetic Pickup Input
22
Mains Contactor Output
23
Generator Contactor Output
23
Digital Outputs
23
Input/Output Extension
24
Port
25
J1939-Canbus Port
25
Usb Device Port
26
Gsm Modem (Optional)
27
Topologies
29
Selecting the Topology
29
Phase, 4 Wire, Star
30
Phase, 3 Wire, Delta
30
Phase, 4 Wire, Delta
31
Phase, 3 Wire, Delta, 2 Ct (L1-L2)
31
Phase, 3 Wire, Delta, 2 Ct (L1-L3)
32
PHASE, 3 WIRE, DELTA, 2 Cts (L1-L2)
32
PHASE, 3 WIRE, DELTA, 2 Cts (L1-L3)
33
Phase, 2 Wire
33
Functionalities
34
Ct Location Selection
34
Amf Functionality
34
Ats Functionality
34
Remote Start Functionality
34
Engine Controller Functionality
35
Remote Display Unit Functionality
36
400Hz Operation
36
Connection Diagrams
37
AMF FUNCTIONALITY, Cts at LOAD SIDE
37
AMF FUNCTIONALITY, Cts at ALTERNATOR SIDE
38
Ats Functionality
39
Remote Start Functionality
40
Engine Control Functionality
41
Remote Display Panel Functionality
42
Terminal Description
43
Technical Specifications
46
Description of Controls
47
Front Panel Functionality
47
Pushbutton Functions
48
Display Screen Organization
49
Automatic Display Scroll
50
Measured Parameters
51
Led Lamps
52
Waveform Display & Harmonic Analysis
53
Displaying Event Logs
55
Statistical Counters
57
Fuel Filling Counter
57
Fuel Consumption Monitoring
58
Operation of the Unit
59
Quick Start Guide
59
Stop Mode
59
Auto Mode
60
Run Mode, Manual Control
61
Test Mode
61
Protections and Alarms
62
Disabling All Protections
63
Service Request Alarm
63
Shutdown Alarms
64
Loaddump Alarms
65
Warnings
66
Non-Visual Warnings
68
Programming
69
Resetting to Factory Defaults
69
Entering the Programming Mode
70
Navigating between Menus
71
Modifying Parameter Value
72
Programming Mode Exit
73
Program Parameter List
74
Controller Configuration Group
74
Electrical Parameters Group
80
Engine Parameters Group
87
Adjust Date and Time
94
Weekly Operation Schedule
94
Exerciser Schedule
95
Sender Configuration
96
Digital Input Configuration
98
Output Configuration
100
Site ID String
102
Engine Serial Number
102
Modem1-2/Sms1-2-3-4 Telephone Numbers
102
Gsm Modem Parameters
103
Ethernet Parameters
104
Crank Cutting
105
Overcurrent Protection (Idmt)
106
Motorized Circuit Breaker Control
108
J1939 Canbus Engine Support
110
Gps Support
114
Gsm Configuration
116
Central Monitoring of Gensets
116
E-Mail Sending
116
Sms Commands
117
Software Features
119
Load Shedding / Dummy Load
119
Load Add / Substract
120
Five Step Load Management
121
Remote Start Operation
122
Disable Auto Start, Simulate Mains
122
Battery Charging Operation, Delayed Simulate Mains
123
Dual Genset Mutual Standby Operation
124
Multiple Voltage and Frequency
125
Single Phase Operation
125
External Control of the Unit
125
Automatic Exerciser
126
Weekly Operation Scheduler
126
Engine Heating Operation
127
Engine Idle Speed Operati̇on
127
Engine Block Heater
127
Fuel Pump Control
128
Gas Engine Fuel Solenoid Control
128
Pre-Transfer Signal
128
Charging the Engine Battery
129
Externally Controlled Digital Outputs
129
Combat Mode
129
Resetting the Controller
130
Automatic Connection Topology Determination
130
Zero Power at Rest
131
Modbus Communications
132
Parameters Required for Rs-485 Modbus Operation
133
Data Formats
133
Declaration of Conformity
136
Maintenance
136
Disposal of the Unit
136
Rohs Compliance
136
Troubleshooting Guide
137
