D-500L
Firmware V-
5.
8
K35D03-EN -
69
-
In order to resume to the
factory set paramete
r values:
-hold pressed the
ST
OP, LAMP TEST
and
ALARM MUTE
buttons f
or 5 seconds,
-
“
RETURN T
O FACTORY SET
” will be displa
yed
-immediately press and ho
ld pressed
RIGHT
ARROW
button f
or 5 seconds
-factory set values will be r
eprogramm
ed to the parameter m
emor
y
.
Hold pressed
STOP, LAMP TEST
and
ALARM MUTE
Hold pressed
RIGHT ARROW
15.1. RESETTING
TO FA
CTORY DEFA
ULT
S
15. PROGRA
M
MING
68
