DK-45 Kullanım Kılavuzu V1.0 (22.09.2016)
- 7 -
Although the controller is protected against electromagnetic disturbance, excessive
disturbance can affect the operation, measurement precision and data communication
quality.
 ALWAYS remove plug connectors when inserting wires with a screwdriver.
 Fuses must be connected to the power supply and phase voltage inputs, in
close proximity of the controller.
 Fuses must be of fast type (FF) with a maximum rating of 6A.
 Use cables of appropriate temperature range.
 Use adequate cable section, at least 0.75mm
2
(AWG18).
 Follow national rules for electrical installation.
 Connect only the provided serial port adapter to the serial communication
port.
Do not install the controller close to high
electromagnetic noise emitting devices like
contactors, high current busbars, switchmode power
supplies and the like.
1.3. ELECTRICAL INSTALLATION

Datakom DK-45 Specifications

Power

supply voltage	305 – 460 VAC
supply frequency	50 - 60Hz
power consumption	< 4 VA

Measurement Inputs

voltage input range phase-phase	20 - 520 V AC
voltage input range phase-neutral	10 - 300 V AC
frequency input range	30 - 100 Hz

Relay Outputs

relay output current	5A
relay output voltage	250V AC
burden	< 0.1VA per phase

Operating Environment

operating temperature	-20°C to +70 °C
storage temperature	-40°C to +80 °C
max. relative humidity	%95 non condensing

Physical Characteristics

dimensions	133x107x46mm
panel cutout	117x87mm minimum
weight	350 gr
