DK-45 Kullanım Kılavuzu V1.0 (22.09.2016)
- 18 -
Following the selection of the program parameter F.02 Stop Service Request, the expiration of a service
timer may simply cause a visual warning and the activation of the alarm relay, or it may also cause below
behaviour:
TIME TO SERVICE
ACTION TAKEN
> 100 hours
No warning occurs
100 hours
Service request warning is given and the service led turns on. The
compressor continues normal operation.
0 hours
The compressor stops. Service request warning is given and the service led
turns on. The compressor may be run again by depressing the RUN
pushbutton.
-100 hours
The compressor stops. Service request warning is given and the service led
turns on. The compressor may be run again by depressing the RUN
pushbutton.
Between -120 and -200 hours,
every 20 hours
The compressor stops. Service request warning is given and the service led
turns on. The compressor may be run again by depressing the RUN
pushbutton.
Between -210 and -300 hours
and every 10 hours
The compressor stops. Service request warning is given and the service led
turns on. The compressor may be run again by depressing the RUN
pushbutton.
-300 hours
The compressor stops. Service request warning is given and the service led
turns on. The compressor will run only after service is performed.
5.1. SERVICE ALARM OPTIONS
