Datakom DK-45 User Manual

DK-45 Kullanım Kılavuzu V1.0 (22.09.2016)
- 37 -
Below is the list of all possible parameters. The description section gives first the parameter name in
uppercase letters as it appears on the screen, then the description of it in lowercase letters.
Please see chapter 6.6.
ICON and No:
DESCRIPTION
ADJUSTMENT LIMITS
Factory
Set
B.01
DISP TEMP.IN F :
Display temperature in
degrees F.
0:Celcius
1:Fahrenheit
0
B.02
MODBUS ADDRESS :
1: Starts multi-compressor operation
2... 254: Modbus address
9
B.03
TIMETO.SLV.STRT :
Slave start timer
(Multi-compressor)
1...999 sec
11 sec
B.04
MASTER CH.TIM :
Master change timer
(Multi-compressor)
0.1 ... 999.9 hour
4.0 hour
B.05
SERI.NO.LOW WRD :
Serial number (lower 16
bits)
0 ... 65535
10
B.06
SERI.NOHGH WRD :
Serial number (higher 16
bits)
0 ... 65535
10
B.07
SHOW PSI :
Show pressure in PSI
0: pressure displayed in bars
1: pressure displayed in PSI
0
10.2. LIST OF PARAMETERS
Some of the parameters in this list may not apeear on the
controller.
10.2.1. ALARM HISTORY
10.2.2. CONFIGURATION

Datakom DK-45 Specifications

Power

supply voltage	305 – 460 VAC
supply frequency	50 - 60Hz
power consumption	< 4 VA

Measurement Inputs

voltage input range phase-phase	20 - 520 V AC
voltage input range phase-neutral	10 - 300 V AC
frequency input range	30 - 100 Hz

Relay Outputs

relay output current	5A
relay output voltage	250V AC
burden	< 0.1VA per phase

Operating Environment

operating temperature	-20°C to +70 °C
storage temperature	-40°C to +80 °C
max. relative humidity	%95 non condensing

Physical Characteristics

dimensions	133x107x46mm
panel cutout	117x87mm minimum
weight	350 gr
