The secondary temperature sensor or a Motor PTC may be connected to the terminal 17 (TEMP.2/PTC)
input of the controller.
If a motor PTC sensor is connected, then E.16 Temp.2 Sensor parameter should be 0 and E.12 Motor
PTC parameter should be 1.
In this case, when the motor overheats and the motor PTC impedence goes over 2000 ohms, the
controller will give ALARM 09 Motor PTC High Temperature.
6.10. MOTOR PTC INPUT

Datakom DK-45 Specifications

Power

supply voltage	305 – 460 VAC
supply frequency	50 - 60Hz
power consumption	< 4 VA

Measurement Inputs

voltage input range phase-phase	20 - 520 V AC
voltage input range phase-neutral	10 - 300 V AC
frequency input range	30 - 100 Hz

Relay Outputs

relay output current	5A
relay output voltage	250V AC
burden	< 0.1VA per phase

Operating Environment

operating temperature	-20°C to +70 °C
storage temperature	-40°C to +80 °C
max. relative humidity	%95 non condensing

Physical Characteristics

dimensions	133x107x46mm
panel cutout	117x87mm minimum
weight	350 gr
