Datakom DK-45 User Manual

DK-45 Kullanım Kılavuzu V1.0 (22.09.2016)
- 61 -
The alarm record is 32 bytes long. Every bit shows the existency of a given alarm.
BIT NO
DESCRIPTION
1
Low voltage
2
High voltage
3
Low frequency
4
High frequency
5
-
6
Fan motor high temperature
7
High temperature alarm
8
Temperature sensor failure
9
Low temperature alarm
10
Pressure safetyy switch open
11
High pressure
12
Pressure sensor failure
13
Emergency stop
14
-
15
Voltage unbalance
16
Motor PTC High temperature alarm
17
-
18
Phase sequence failure
19
Temperature sensor-2 failure
20
High temperature-2 alarm / Delta (tS2-tS1) alarm
21
Low temperature-2 alarm
22
Pressure sensor-2 failure
23
High pressure-2
24
High delta pressure
25
Motor overload
26
Low pressure-2
27-32
-
11.3. ALARMS, WARNINGS, SERVICE REQUESTS

Datakom DK-45 Specifications

Power

supply voltage	305 – 460 VAC
supply frequency	50 - 60Hz
power consumption	< 4 VA

Measurement Inputs

voltage input range phase-phase	20 - 520 V AC
voltage input range phase-neutral	10 - 300 V AC
frequency input range	30 - 100 Hz

Relay Outputs

relay output current	5A
relay output voltage	250V AC
burden	< 0.1VA per phase

Operating Environment

operating temperature	-20°C to +70 °C
storage temperature	-40°C to +80 °C
max. relative humidity	%95 non condensing

Physical Characteristics

dimensions	133x107x46mm
panel cutout	117x87mm minimum
weight	350 gr
