Figure C – Display and Keypad Panel
Programming Keypad
Power On LED (Green)
Phase On LED
(
Yellow
)
Encoder LED (Yellow)
1
2
3
4
TX Data LED (Green)
Network LED (Red)
LCD Display
5
6
7
Figure D – Connector Panel for Standard Models
Lonworks 17-pin male connector
Lonworks 17-pin female connector
1
2
Serial interface and I/O 26-pin connector
3
1
2
3
1
4
2 3
4 5 6
1 7
3
2
Figure E – Connector Panel for Ethernet Models
Lonworks 17-pin male connector
Lonworks 17-pin female connector Harting RJ modular connector
1
2
4
Serial interface and I/O 26-pin connector
3
x
