Linking the Reader
Quick Reference Guide 19
Linking the Reader
Link Datalogic RF Devices to Base
For RF devices, before configuring the interface it is necessary
to link the handheld with the base.
To link the handheld and the base, either press the trigger to
wake it, or simply mount into the base to wake up for opera-
tion. If the reader was previously linked to another base, you
must first scan the
Unlink barcode before re-linking to the new
base.
Link Scanner to Bluetooth Adapter
1. Install any drivers provided with the Bluetooth
adapter.
2. Scan the
Enable RF Link to Server label below to make the
scanner visible to the host computer.
3. Use the host computer’s Bluetooth manager to “Dis-
cover new devices” and select "Datalogic Scanner." If
you receive an error message, it may be necessary to
disable security on the device.
4. Use an RS-232 terminal program to see incoming
data on the port designated by the computer's Blue-
tooth manager.
Unlink
Enable RF Link to Server

Datalogic Gryphon I GBT4400 2D Specifications

General

Scanner Type	2D Imager
Connectivity	Bluetooth
IP Rating	IP52
Print Contrast Ratio (Minimum)	25%
Interface	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Drop Resistance	1.8 m (6 ft) to concrete
Weight	245 g / 8.64 oz
Dimensions	18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in
Light Source	Red LED
Image Sensor	CMOS
Decode Capability	1D / 2D / Postal / Stacked codes
Scanning Technology	Imaging
Resolution	752 x 480 pixels
Skew Angle	+/- 65°
Humidity	5 to 95% non-condensing
Drop Specification	1.8 m (6 ft) to concrete
Power Supply	5 VDC +/- 5%
Beeper	Yes
Indicators	LEDs, Beeper
Supported Barcodes	All standard 1D and 2D barcodes
