Datalogic Gryphon I GBT4400 2D User Manual

Table of Contents
Software Product Policy .............................................................................4
Customers Under Software Support ..........................................4
Description .....................................................................................................5
Setting Up the Reader ................................................................................6
Positioning the Base Station .........................................................6
Changing the Base Station Position ................................ 6
Connecting the Base Station ....................................................................8
Securing the DC Power Cord (Optional) ........................ 9
System and Network Layout ...................................................... 11
Typical Setup with Cradle and Host.............................. 11
Using the BC40xx™ Radio Base ..................................................12
Radio Base LEDs ................................................................... 12
Charging the Batteries .............................................................................13
Battery Safety ...................................................................................13
Replacing the Batteries ................................................................16
Using the Gryphon™ I GBT4400 2D .....................................................18
Linking the Reader ....................................................................................19
Link Datalogic RF Devices to Base................................. 19
Link Scanner to Bluetooth Adapter............................... 19
Power Off ......................................................................................................20
Selecting the Interface Type ..................................................................20
Interface Selection .........................................................................20
Configuring the Interface ................................................. 20
Keyboard Interface.............................................................. 23
Scancode Tables .................................................................. 25
Country Mode....................................................................... 25
Caps Lock State .................................................................... 30
Numlock.................................................................................. 31
Programming ..............................................................................................32
Using Programming Barcodes ...................................................32
Configure Other Settings ............................................................. 32
Resetting Standard Product Defaults ......................................32
Reading Parameters .................................................................................33
Aiming System ................................................................................33
Good Read Green Spot Duration ..............................................34

Datalogic Gryphon I GBT4400 2D Specifications

General

Scanner Type	2D Imager
Connectivity	Bluetooth
IP Rating	IP52
Print Contrast Ratio (Minimum)	25%
Interface	USB, RS-232, Keyboard Wedge
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-20 to 70 °C / -4 to 158 °F
Drop Resistance	1.8 m (6 ft) to concrete
Weight	245 g / 8.64 oz
Dimensions	18.1 x 7.1 x 10.0 cm / 7.1 x 2.8 x 3.9 in
Light Source	Red LED
Image Sensor	CMOS
Decode Capability	1D / 2D / Postal / Stacked codes
Scanning Technology	Imaging
Resolution	752 x 480 pixels
Skew Angle	+/- 65°
Humidity	5 to 95% non-condensing
Drop Specification	1.8 m (6 ft) to concrete
Power Supply	5 VDC +/- 5%
Beeper	Yes
Indicators	LEDs, Beeper
Supported Barcodes	All standard 1D and 2D barcodes
