Connecting the Base Station
Quick Reference Guide 11
Disconnecting the Cable:
To detach the cable, insert a paper clip
or similar object into the hole on the base, as shown in Figure
5.
Figure 5. Disconnecting the Cable
System and Network Layout
Typical Setup with Cradle and Host
Figure 6. Reader Layout
Gryphon 2D GBT can also be Powered by the Terminal. The
external power supply is recommended but not necessary.
When powered by the Terminal, the battery charger is auto-
matically set as Slow charge.
Insert
Paper Clip
