Product Reference Guide 215
2D Symbologies
The reader supports the following 2D symbologies (bar code types). Symbol-
ogy-dependent options for each symbology are included in this chapter. See
"1D Symbologies" starting
on page 113
for configuration of 1D bar codes.
2D Symbologies
• AZTEC CODE on page 218 • MICRO PDF417 on page 233
•
CHINA SENSIBLE CODE on page 221 • QR CODE on page 236
•
DATA MATR IX on page 224 • MICRO QR CODE on page 239
•
MAXICODE on page 227 • UCC COMPOSITE on page 242
• on page 230 •
POSTAL CODE SELECTION on page 243
2D Global Features
The following features are common to all, or in some cases, most of the available
2D symbologies. Default settings are indicated at each feature/option with a
green arrow. Also reference
Appendix B, Standard Defaults for a listing of the
most widely used set of standard facto
ry settings. That section also provides
space to record any custom settings needed or implemented for your system.
To set most features:
1. Scan the ENTER/EXIT PROGRAMMING bar c
ode at the top of applicable pro-
gramming pages.
2. Scan the correct bar code to set the desired program
ming feature or parame-
ter. You may need to cover unused bar co
des on the page, and possibly the
facing page, to ensure that the reader reads only the bar code you intend to
scan.
3. If additional input parame
ters are needed, go to
Appendix D, Keypad, and
scan the appropriate characters from
the keypad.
NOTE
Additional information about many features can
be found in the “References” chapter.
If you make a mistake before the last character,
scan the CANCEL bar code to abort and not save
the entry string. You can then start again at the beginning.
Complete the programming sequence by scanning the ENTER/EXIT PROGRAM-
MING bar code to exit Programming Mode.
2D Global Features
• 2D MAXIMUM DECODING TIME on page
216
• 2D NORMAL/INVERSE SYMBOL CONTROL
on page 217
•
2D STRUCTURED APPEND on page 217
PDF417
