Datalogic GRYPHON User Manual

Exit and Save Configuration
ADVANCED FORMATTING
Ì$
-
?Î
120
Read the above code + two numbers in the range 01 to 99 representing the character
position in the code where the first character of the predefined string must be found.
Read 00 if the match string can be found in any character position.
5
Divide Code into Fields
divide code into fields
ÌHF.Î
Read one number in the range 1 to 5 to divide the code into fields.
6 Define Code Fields
define code fields
Each code field length can be set by either:
a) defining a field separator character to be found in the code itself. In this case you can
choose to discard the code separator character or include it as the last character of the
field.
OR BY
b) specifying a specific character length
up to the maximum of 99 characters.
OR BY
c) selecting the last field as variable length (if any).
You must define the same number of fields as selected in step 5, including fields that will
not be transmitted.

Datalogic GRYPHON Specifications

General

Scanner Type	Handheld
Category	Barcode Reader
Drop Resistance	1.8 meters
IP Rating	IP65
Decoding Capability	1D and 2D barcodes
Light Source	LED
Scan Pattern	Linear or omnidirectional (depending on model)
Model	GRYPHON
Type	Handheld
Scan Technology	Laser or Imager (depending on model)
Humidity	5 to 95% NC (Non-Condensing)
Dimensions	Varies by model
Weight	Varies by model
Power Supply	Battery (Cordless Models)
Storage Temperature	-20°C to 60°C
