GRYPHON™
170
WEDGE (continued)
DESCRIPTION STRING
Caps Lock caps Lock ON
FE1
caps Lock OFF
FE0
Caps Lock Auto-Recognition disable
FP0
(IBM AT compatible only) enable
FP1
Num Lock Toggle Num Lock
FL1
Num Lock Unchanged
FL0
Inter-Character (ms)
CK00 - CK99
Delays
Inter-Code
(s)
FG00 - FG99
PEN
DESCRIPTION STRING
Operating mode
interpret (does not require $+ or $-) $]
transparent (does not require $+ or $-) $[
Minimum output pulse
200μs
DG0
400μs
DG1
600μs
DG2
800μs
DG3
1 ms
DG4
1.2 ms
DG5
Conversion to Code 39 and
Code 128
disable conversion to Code 39
(D series only)
DA0
enable conversion to Code 39
DA1
enable conversion to Code 128
(M series only)
DA2
Output level normal
DD0
inverted
DD1
Idle level normal
DE0
inverted
DE1
Overflow narrow overflow
DH0
medium overflow
DH1
wide overflow
DH2
Inter-Block delay (100 ms)
CK00-CK99
IBM 46xx
DESCRIPTION STRING
IBM Data Formatting Code 39 Format
GD0
IBM Standard Format
GD1
Mixed IBM Standard + Code 39 Format
GD2
