Datalogic QuickScan i QD2100 User Manual

Data Editing
104 QuickScan
TM
QD2100
Table 17. Label ID Pre-loaded Sets
Symbology USA Label ID set EU Label ID set
ASCII
character
Hex
value
ASCII
character
Hexidecimal
value
ABC Codabar S 530000 S 530000
Anker Plessey o 6F0000 o 6F0000
CODABAR % 250000 R 520000
Codablock F l 6C0000 m 6D0000
Code 39 CIP Y 590000 Y 590000
Code 93 & 260000 U 550000
CODE11 CE 434500 b 620000
CODE128 # 230000 T 540000
CODE32 A 410000 X 580000
CODE39 * 2A0000 V 560000
CODE4 4 340000 4 340000
CODE5 j 6A0000 j 6A0000
CODE93 & 260000 U 550000
DATALOGIC 2OF5 s 730000 s 730000
EAN13 F 460000 B 420000
EAN13 P2 F 460000 L 4C0000
EAN13 P5 F 460000 M 4D0000
EAN13 P8 F 460000 # 230000
EAN8 FF 464600 A 410000
EAN8 P2 FF 464600 J 4A0000
EAN8 P5 FF 464600 K 4B0000
EAN8 P8 FF 464600 * 2A0000
FOLLETT 2OF5 O 4F0000 O 4F0000
GS1 DATABAR EXPANDED RX 525800 t 740000
GS1 DATABAR LIMITED RL 524C00 v 760000
GS1 DATABAR OMNIDIRECTIONAL R4 523400 u 750000
GS1-128 000000 k 6B0000
GTIN G 470000 $A 244100
GTIN2 G2 473200 $B 244200
GTIN5 G5 473500 $C 244300
GTIN8 G8 473800 $D 244400

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
