Datalogic QuickScan i QD2100 User Manual

Symbologies
144 QuickScan
TM
QD2100
Add-Ons
The following features apply to optional add-ons.
NOTE
Contact Customer Support for advanced programming of
op
tional and conditional add-ons.
Optional Add-ons
The reader can be enabled to optionally read the following add-ons (supplementals):
•P2
•P5
• GS1-128
NOTE
ENTER/EXIT PROGRAMMING MODE
DEFAULT
Optional Add-Ons = Disable P2
Optional Add-Ons = Enable P2
DEFAULT
Optional Add-Ons = Disable P5
If a UPC/EAN base label and a an add-on are both decoded, the
reader will transmit the base label and add-on. If a UPC/EAN
base label is decoded without an add-on, the base label will be
transmitted without an add-on.
Conditional add-on settings (if enabled) are considered by the
re
ader before optional add-on settings.

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
